120X120X38mm DC Axial Fan High Temperature Resistance Ball Bearing

Basic Info

Model NO.	TX12038
Material	Plastic
Blade Material	Plastic
Type	DC Fan
Electric Current Type	DC
Mounting	Free Standing
Certification	RoHS, ISO, CE, CCC
Rated Voltage	5V/12V
Safety Rating	En60529
Vibration	10-55Hz, 1.5mm
Atmospheric Pressure(mm)	55kpa(G) 74.8kpa (H)
Impact	150m/S2
Relative Humidity(%)	90%~95%
Bearing System	Ball Bearing
Transport Package	Carton
Specification	120x120x38mm
Trademark	Tesoer
Origin	China
HS Code	8414599050
Production Capacity	50000pieces/Year

Product Description

·An axial fan is a type of fan that causes gas to flow through it in an axial direction, parallel to the shaft about which the blades rotate.
·The flow is axial at entry and exit. The fan is designed to produce a pressure difference, and hence force, to cause a flow through the fan.
·Factors which determine the performance of the fan include the number and shape of the blades.
·Fans have many applications including in wind tunnels and cooling towers.
·Design parameters include power, flow rate, pressure rise and efficiency.
The series of fans are made of cylindrical aluminum alloy for the outer frame,and PBT plastic for the blades;blade and motor integrate into one unit. and installed by double-sided flange, which has the follow feature: small volume, maintenance-free and easy to mounting,and also has the characteristics of low noise and vibration, reliable operation and other excellent performance.

OEM / ODM
OEM orders are welcome on our products. Our experienced engineering team is capable of walking through the design stage with our customers' design. We accept buyers' labels or logos. Our quality standards are available based on customers' demand.

Basic information:

Use of Ambient condition for DC Axial Flow Fan:
Temperature(°C)	ball bearing:(B)-30°C~70°Csleeve bearing:(S)-10°C~40°C
	(Special temperature can be customized, the highest temperature can be up to-40°C~100°C)
Relative humidity(%)	90%~95%
Atmospheric pressure(mm)	55KPa(G)74.8KPa(H)
Vibration	10-55Hz , 1.5mm
Impact	150m/s2
Useful life	The Laboratory temperature at 25°C,the ball bearing can be lasted 70000hours
